Electrocauterio DRE Citadel X3
0 Los artículos están en tu carrito. Mirar Carrito ya.
¿Necesita asesoramiento sobre los equipos? ¡Pregunte a Nuestros Expertos!
(502) 244-6333
Descripción
Completamente nuevo y cuenta con:
- Poder de hasta 300 vatios
- Capacidad monopolar y bipolar
- Capacidad de sellado de Vasos
- Pedal de pie, placa para paciente y pieza de mano
- Módulos de operación para virtualmente todo tipo de cirugía
Especificaciones
Dimensions
- Width: 16.5 in (42 cm)
- Depth: 17.7 in (45 cm)
- Height: 6.9 in (17.5 cm)
- Weight: < 16.53 lbs (7.5 kg)
Power
- Operating voltage: 180-265 V AC
- Max. Power input: 1000 VA
- Fuse: 4 A
- UPS Backup: 1.5 KVA
Monopolar Autocut
- Seven modes, 390 kHz
- Low Cut: Continuous output, 400 W at 300 Ω, CF 1.5, Low Volt
- Pure Cut: Continuous output, 400 W at 300 Ω, CF 1.5
- Blend1: Bursts at 29 kHz, 250 W at 300 Ω, CF 2
- Blend2: Bursts at 29 kHz, 200 W at 300 Ω, CF 2.6
- Endo1: Pulse output, 400 W at 300 Ω, CF 1.5 Low Pulse Intr.
- Endo2: Pulse output, 400 W at 300 Ω, CF 1.5 High Pulse Intr.
- Hydro: Continuous output, 400 W at 300 Ω, CF 1.5, Rapid
Monopolar Coag
- Seven modes: 460 kHz
- Soft: Continuous output, 300 W at 300 Ω, CF 1.5, Low Volt
- Desiccate: Repetition frequency 83 kHz, 200 W at 500 Ω, CF 5.0
- Swift: Repetition Frequency 53 kHz, 120 W at 500 Ω, CF 6.2
- Force: Repetition Frequency 29 kHz, 120 W at 500 Ω, CF 7.0
- Spray: Repetition Frequency 24 kHz, 120 W at 500 Ω, CF 8.0
- Hi-Spray: Repetition Frequency 13 kHz, 70 W at 500 Ω, CF 10.0
- Hydro: Repetition Frequency 29 kHz, 120 W at 500 Ω, CF 7.0
Saline Resection Mode
- Four modes, 440 kHz
- Low Cut: Continuous output 300 W at 100 Ω, CF 1.5, LV
- Standard Cut: Continuous output 300 W at 100 Ω, CF 1.5 HV
- Soft Coag: Continuous output 200 W at 100 Ω, CF 1.5 LV
- Force Coag: Continuous output 200 W at 100 Ω, CF 1.5 HV
Bipolar Coag
- Five modes, 440 kHz
- Micro: Continuous output, 120 W at 100 Ω, CF 1.5, Low Volt
- Standard: Continuous output, 120 W at 100 Ω, CF 1.5, Medium Volt
- Force: Continuous output, 120 W at 100 Ω, CF 1.5, High Volt
- Bip Cut: Continuous output, 120 W at 100 Ω, CF 1.5, Low Volt
- Macro Cut: Continuous output, 120 W at 100 Ω, CF 1.5, High Volt
Vessel Sealing
- Two modes, 440 kHz
- Fine seal: Low Pulse output, 5 levels, 150 W at 100 Ω, CF 1.5
- Rapid seal: High Pulse output, 5 levels, 150 W at 100 Ω, CF 1.5
Feedback System
- 3 Microprocessor Controlled 6SENSE Technology with sampling rate about 4000 sense/second.
- Maximum output power deviation < 15% or 5 watts, whichever is greater at any setting with PER-98
Leakage Currents
- RF leakage current: Monopolar < 150 mA rms, Bipolar < 60 mA rms
- Low Frequency leakage currents: Normal polarity - intact ground < 10 μA, Normal polarity - ground open < 50 μA
